Ensemble Learning = Predicting Diabetes: Classification Use Case

Diabetes Prediction using Classification, KNN algorithm, Ensemble Learning

Author

Mahesh Gurumoorthi
November 03, 2025

About the dataset :

This dataset is designed for beginners in Machine Learning who want to practice building classification models.
It contains 1,000 anonymized patient records, each with medical and demographic features commonly associated with diabetes diagnosis.

• Building a Diabetes Prediction Model

• Practicing Data Cleaning, Feature Engineering, and EDA

• Testing algorithms like Logistic Regression, Decision Trees, or Random Forests

Step 1: Importing Required Libraries and Packages

import numpy as np import pandas as pd import matplotlib.pyplot as plt import seaborn as sns
import warnings warnings.filterwarnings('ignore') %matplotlib inline

Step 2: Reading the dataset using Pandas:

diabetes_data = pd.read_csv('/Users/Sample Datasets Kaggle/diabetes 2.csv')
diabetes_data.head()
diabetes_data.describe()
diabetes_data.info()
diabetes_data.describe().T

Step 3: Perform the exploratory data analysis and validate the null values existing in the dataset before modelling

diabetes_data.isna().sum()
diabetes_data_copy = diabetes_data.copy(deep=True)
diabetes_data_copy.head()
diabetes_data_copy.describe()
diabetes_data_copy.isna().sum()

Note: Checked both diabetes_data and diabetes_data_copy and it has no '0' values

p = diabetes_data_copy.hist(figsize=(20,20))

Note :

Skewness: It is classified into two types: left and right skew.
Left Skewness: It has a long left tail, and it is called a negatively skewed line. This is because there is a long trail line in the negative direction, and the mean is also in the left peak

Right Skewness: It has a long right tail and it is called a positively skewed line. This is because there is a long trail line in the positive direction, and the mean is also in the right peak

Step 5: Plot the histogram view of the Data types of count

plt.figure(figsize=(10,6))
sns.countplot(y = diabetes_data.dtypes, data=diabetes_data)
plt.title('Data Types Count')
plt.ylabel('Data Types')
plt.xlabel('Count of each Data Type')
plt.show()

Step 6: Visualizing missing values using the missingno library

import missingno as msno
msno.bar(diabetes_data)
color_wheel = {1: "#0392cf", 2 : "#ff7f0e"}
colors = diabetes_data['Outcome'].map(lambda x: color_wheel.get(x + 1))
print(diabetes_data['Outcome'].value_counts())
p = diabetes_data.Outcome.value_counts().plot(kind="bar",
                                             figsize=(8,5),
                                             color=["#0392cf", "#ff7f0e"])
plt.title("Diabetes Outcome Distribution")
plt.xlabel("Outcome (0 = No Diabetes, 1 = Diabetes)")
plt.ylabel("Count")
plt.show()

Outcome
1    482
0    482
Name: count, dtype: int64

Note: The above histogram shows that the data is not biased and is equally split

Step 7: Perform the scatter matrix of all the data

from pandas.plotting import scatter_matrix
scatter_matrix(diabetes_data, figsize=(20, 20))
plt.show()

Step 8: Perform the pair plot using the diabetes data (cleaned data)

Note: Pair Plot: Pair plots are represented on the two basic figures, the histogram and scatter plot. The histogram on the diagonal allows us to see the distribution of single variable, while scatter plots on the upper and lower triangles show the relationship between two variables

pr = sns.pairplot(diabetes_data_copy, hue='Outcome')

Hint:

Pearson Correlation Coefficient: This helps to find the relationship between two variables. It gives the measure of strength of association between two variables. The value of the Pearson Correlation Coefficient can be between -1 and +1, which means they are highly correlated, and 0 means no correlation.

HeatMap: A heatmap is a two-dimensional representation of information with the help of colours. Heat maps can help the user visualize simple or complex information

Step 9: Perform the correlation matrix

plt.figure(figsize=(10,6))
p = sns.heatmap(diabetes_data.corr(), annot=True, cmap ='RdYlGn')
plt.title("Diabetes Data Feature Correlation Heatmap", fontsize=16)
plt.show()
diabetes_data.corr()

Hint:

Scaling the data: data Z is rescaled such that mu (mean) = 0 and sigma = 1. Difference between xi and mu(mean) divided by sigma

Step 10: Standardization is essential before modelling because it ensures that all features contribute equally to the model, especially when they’re measured on different scales. Without it, models can become biased toward features with larger numeric ranges

from sklearn.preprocessing import StandardScaler
sc_X = StandardScaler()
X =  pd.DataFrame(sc_X.fit_transform(diabetes_data_copy.drop(["Outcome"],axis = 1),),
        columns=['Pregnancies', 'Glucose', 'BloodPressure', 'SkinThickness', 'Insulin',
       'BMI', 'DiabetesPedigreeFunction', 'Age'])

Step 10: Split the training and testing data before modelling.

Train test split: Unknown datapoints to test the data, rather than testing with the same points with which the model was trained. Ideally 70-30 principle is used.

Cross Validation: When a model is split into the training and testing, it is possible that a specific type of data point may go entirely into either the training or the testing portion. This would lead the model to perform badly; hence, overfitting and underfitting problems can be well avoided with cross-validation techniques

Stratify: This parameter makes a split so that the proportion of values in the sample produced will be the same as the proportion of values provided in the parameter stratify.
For instance, if a variable is a binary categorical variable with values of 0 and 1, then there are 25% of zeros and 75% of ones. It stratifies will be equal to y, this will make sure that the random split has 25% of 0’s and 75% of 1’s

from sklearn.model_selection import train_test_split
X_train, X_test, y_train, y_test = train_test_split(X, y, test_size=0.3, random_state=42, stratify=y)
from sklearn.neighbors import KNeighborsClassifier
test_scores = []
train_scores = []

for i in range(1,15):
    knn = KNeighborsClassifier(n_neighbors=i)
    knn.fit(X_train, y_train)

    train_score = knn.score(X_train, y_train)
    test_score = knn.score(X_test, y_test)

    train_scores.append(train_score)
    test_scores.append(test_score)
## score that comes from the testing data on the same datapoints on which model was trained
max_train_score = max(train_scores) train_cores_ind = [i for i, v in enumerate(train_scores) if v == max_train_score] print(f'Maximum Train Score is {max_train_score * 100} at K={train_cores_ind[0]+1}') Maximum Train Score is 100.0 at K=1
## score that comes from the testing data on the same datapoints on which model was tested solely
max_test_score = max(test_scores) test_cores_ind = [i for i, v in enumerate(test_scores) if v == max_test_score] print(f'Maximum Test Score is {max_test_score * 100} at K={test_cores_ind[0]+1}') Maximum Test Score is 54.82758620689655 at K=14

Step 11: Validation Result

Outcome of the above line plot :
The best result is captured at k = 6 hence 6 is used for the final model¶

knn = KNeighborsClassifier(n_neighbors=6)
knn.fit(X_train, y_train)
knn.score(X_test, y_test)

0.5206896551724138

Step 12: Ensemble Learning

Ensemble learning is based on the idea that a group of weak learners can combine their efforts to form a stronger learner. Instead of relying on one model, it aggregates the predictions of several models to produce more accurate and stable results. In this use case, we are going to break the clusters into 2 which means Knearest neighbours = 5 & 10 and decision tree.

from sklearn.neighbors import KNeighborsClassifier
from sklearn.tree import DecisionTreeClassifier
knn_5 = KNeighborsClassifier(n_neighbors=5)
knn_5.fit(X_train, y_train)
knn_5.score(X_test, y_test)
0.49310344827586206

knn_10 = KNeighborsClassifier(n_neighbors=10)
knn_10.fit(X_train, y_train)
knn_10.score(X_test, y_test)
0.46551724137931033

decision_tree = DecisionTreeClassifier(random_state=42)
decision_tree.fit(X_train, y_train)
decision_tree.score(X_test, y_test)
0.5310344827586206

Step 13: Train the individual models and ensemble it :

for clf in (knn_5, knn_10, decision_tree):
    clf_name = clf.__class__.__name__
    train_score = clf.score(X_train, y_train)
    test_score = clf.score(X_test, y_test)
    print(f'{clf_name}: Train Score: {train_score*100:.2f}%, Test Score: {test_score*100:.2f}%')
KNeighborsClassifier: Train Score: 69.44%, Test Score: 49.31%
KNeighborsClassifier: Train Score: 60.39%, Test Score: 46.55%
DecisionTreeClassifier: Train Score: 100.00%, Test Score: 53.10%

Step 14: Evaluate the quality of the test set

for name, clf in (('KNN 5', knn_5), ('KNN 10', knn_10), ('Decision Tree', decision_tree)):
    y_pred = clf.predict(X_test)
    from sklearn.metrics import classification_report, confusion_matrix
    print(f'---{name}---')
    print('Confusion Matrix:')
    print(confusion_matrix(y_test, y_pred))
    print('\nClassification Report:')
    print(classification_report(y_test, y_pred))
---KNN 5---
Confusion Matrix:
[[73 72]
 [75 70]]

Classification Report:
              precision    recall  f1-score   support

           0       0.49      0.50      0.50       145
           1       0.49      0.48      0.49       145

    accuracy                           0.49       290
   macro avg       0.49      0.49      0.49       290
weighted avg       0.49      0.49      0.49       290

---KNN 10---
Confusion Matrix:
[[87 58]
 [97 48]]

Classification Report:
              precision    recall  f1-score   support

           0       0.47      0.60      0.53       145
           1       0.45      0.33      0.38       145

    accuracy                           0.47       290
   macro avg       0.46      0.47      0.46       290
weighted avg       0.46      0.47      0.46       290

---Decision Tree---
Confusion Matrix:
[[80 65]
 [71 74]]

Classification Report:
              precision    recall  f1-score   support

           0       0.53      0.55      0.54       145
           1       0.53      0.51      0.52       145

    accuracy                           0.53       290
   macro avg       0.53      0.53      0.53       290
weighted avg       0.53      0.53      0.53       290

Conclusion on ensemble modelling: Decision tree is the best method for this use case because it performs well compared to the other 2 models (K nearest neighbour = 5 & 10)

Other Key Metrics for additional purpose

Step 1: Confusion Matrix

from sklearn.metrics import confusion_matrix, classification_report
y_pred = knn.predict(X_test)
confusion_matrix(y_test, y_pred)
pd.crosstab(y_test, y_pred, rownames=['Actual'], colnames=['Predicted'], margins=True)
from sklearn import metrics
y_pred = knn.predict(X_test)
conf_matrix = metrics.confusion_matrix(y_test, y_pred)
p = sns.heatmap(conf_matrix, annot=True, fmt="d")
plt.title("Confusion Matrix")
plt.ylabel('Actual Values')
plt.xlabel('Predicted Values')
plt.show()

Hint :

 TP – True Positives
    FP – False Positives

    Precision – Accuracy of positive predictions.
    Precision = TP/(TP + FP)
FN – False Negatives Recall(sensitivity or true positive rate): Fraction of positives that were correctly identified. Recall = TP/(TP+FN)
  F1 Score (aka F-Score or F-Measure) – A helpful metric for comparing two classifiers.
    F1 Score takes into account precision and the recall.
    It is created by finding the the harmonic mean of precision and recall.

    F1 = 2 x (precision x recall)/(precision + recall)
from sklearn.metrics import classification_report
print(classification_report(y_test, y_pred))

Step 2: Perform ROC - AUC Curve

from sklearn.metrics import roc_auc_score
plt.plot([0,1],[0,1],'k--')
plt.plot(fpr,tpr, label='Knn')
plt.xlabel('fpr')
plt.ylabel('tpr')
plt.title('Knn(n_neighbors=11) ROC curve')
plt.show()
from sklearn.metrics import roc_auc_score
roc_auc_score(y_test, y_pred_prob)

np.float64(0.5056361474435196)
from sklearn.model_selection import GridSearchCV param_grid = {'n_neighbors': np.arange(1,25)} knn = KNeighborsClassifier() knn_gscv = GridSearchCV(knn, param_grid, cv=5) knn_gscv.fit(X_train, y_train) print('Best Score: ', knn_gscv.best_score_) Best Score: 0.550480928689884
